Engenius Senao 200mw Enterprise Access Point 2511-ap-pro-plus



return to store



2511-AP-PRO-PLUS

Click for our price





PDF operations manual

PDF specs


Antenna Detachable A ntenna (TNC connector)
RF Output Power Transmit Power Control (20mW-200mW)
23dBm(200mW) FCC; 20dBm(100mW) CE
Compatibility IEEE 802.11b compliant
Regulation Certifications FCC Part 15/UL, ETSI 300/328/CE
Network
Interface One RJ-45 1 (10/100BaseTX) Port
Security - IEEE 802.1x/Radius Client(EAP-MD5/TLS/TTLS)
- 64/128-bit WEP encryption
- Hide SSID in beacons, and deny any SSID
- Wireless Client Isolation
- TCP/IP/UDP/Port/MAC address filtering
VPN Support IP Sec pass-through / PPTP
Management -Telnet/Web/SNMP(v1/v2, 802.11MIB) configuration
-HW/SW Watch dog
-Load balance
Firmware Upgrade Upgrade firmware via TFTP/Web-based
Environment
Temperature Range 0 to 55 C (32 F to 131 F) - Operating,
-20 to 80 C(-4 F to 176 F) - Storage
Humidity (non-condensing) 5%

Range (open environment)
11 Mbps: 300m/450m
5.5 Mbp:
400m/600m
2 Mbps: 500m/750m
1 Mbps: 800m/1200m

Rec. Sensitivity (@FER=0.08)
11 Mbps <-87dbm
5.5 Mbps <-90dbm
2 Mbps <-93dbm
1 Mbps <-95dbm

Network Information
Interface: One 10/100Mbps RJ-45 LAN Port
Firmware Upgrade: Upgrade firmware via TFTP
Security: Mac address filtering, WEP encryption, Hide SSIS in beacons, stations cannot use "any" ssid
IP Auto-configuration: DHCP Client/Server/Relay
Mangement:
Web-based configuration, SNMP Management

Radio
Frequency Band: 2.4 2.484 GHz
Radio Type: Direct Sequence Spread Spectrum (DSSS)
Modulation: CCK (11, 5.5Mbps) DQPSK (2Mbps) DBPSK (1Mbps)
Operation: Channels 11 for North America, 14 for Japan, 13 for Europe, 2 for Spain, 4 for France
RF Output Power: 23dBm(200mW)--FCC
Antenna: RP-TNC-MALE



SNMP walk output
