Engenius Senao USB Device 2511-UB

return to store

New super small design! We have had good results with this USB client very long range and good connection.

Click for our price

Click here for users manual

Click here for spec sheet

 Specifications
Product Wireless USB Adapter
Model no. NL-2511UB4 MERCURY
General
Radio Data Rate 11, 5.5, 2 and 1 Mbps, Auto Fall-Back
Range (open
environment)
11 Mbps – 150m
5.5 Mbps – 200m
2 Mbps – 250m
1 Mbps – 400m
Operating Voltage 5V
EMC Certifications FCC Part 15/UL, ETSI 300/328/CE
Compatibility Fully interoperable with IEEE802.11b compliant
products
LED Indicator RF Link activity
Network Information
Network Architecture Support ad-hoc, peer-to-peer networks and
infrastructure communications to wired Ethernet
networks via Access Point
Drivers Windows 98/ME/2000/XP
Access Protocol CSMA/CA
Roaming IEEE802.11b compliant
Security 64/128-bit WEP data encryption
Radio
Frequency Band 2.4 – 2.484 GHz
Radio Type Direct Sequence Spread
Spectrum (DSSS)
Modulation CCK (11, 5.5Mbps)
DQPSK (2Mbps)
DBPSK (1Mbps)
Operation Channels 11 for North America, 14 for Japan,
13 for Europe, 2 for Spain, 4 for
France
RF Output Power 15dBm + 2dBm
Antenna High Sensitivity Dipole Antenna
Sensitivity @FER=0.08 11 Mbps < -83dBm
5.5 Mbps < -86dBm
2 Mbps < -89dBm
1 Mbps < -91dBm
Environmental
Temperature Range 0 to 50 (operating)
-20 to 80 (storage)
Humidity
(non-condensing)
5% to 95% typical
Physical Specifications
Form Factor USB 1.1

Description:
